Documentation - settings.ini

• database_ext Extension of database files.
• fits_ext Extension of FITS files.
• period_length Length of a calibration period (Julian Date) [default: 0.04167 = 1h].
• query_select_tod_time Load timestamps for a given DA from a TOD database.
• query_select_tod_temp Load temperature data for a given detector from a TOD database.
• query_select_pointing Load pointing data from a TOD database.
• query_insert_tmp_mask Create a temporary table for rowids masked out from the current DA. This table is then used to filter TOD in model fitting.
• query_select_tod_mod Load TOD for model fitting (pointing + temperature) from a TOD database.
• query_select_attitude Load attitude data (velocities) from a TOD database.
• query_select_sol_cal Load calibration solutions (gain + baseline) from a solution database.
• query_insert_sol_cal_1 Save calibration solutions (linear).
• query_insert_sol_cal_2 Save calibration solutions (non-linear).
• query_insert_residuals Save calibration residuals.
• query_update_tod_temp Reduce raw TOD.
• query_select_det_tbls Retrieve names of detector tables from a TOD database.

query_select_tod_mod = CREATE TEMPORARY TABLE IF NOT EXISTS _DA_cache AS SELECT rowid, frmInd, thetaA, phiA, thetaB, phiB FROM _TOD._DA WHERE ((sciInd NOT IN (SELECT rowid FROM _TOD.TELEMETRY WHERE (((genflags <> 0) AND (genflags <> 192)) OR (_DA <> 0)))) AND rowid NOT IN (SELECT id FROM _DA_mask) AND ((ABS(thetaA) > 15.0) AND (ABS(thetaB) > 15.0))));SELECT frmInd, thetaA, phiA, thetaB, phiB, dtemp FROM _TOD._DET INNER JOIN _DA_cache ON _TOD._DET.rowid = _DA_cache.rowid WHERE ((_DA_cache.rowid >= _BEG) AND (_DA_cache.rowid <= _END));

Select data for model fitting. Note the use of a temporary in-memory table to speed up repetitive JOIN operations. The blue term demonstrates how to selectively allow certain quality flags to enter the fit. The green part is responsible for masking. The red term shows how to exclude additional pointings from the fit.

query_select_det_tbls = SELECT name FROM _TOD.sqlite_master WHERE ((type = 'table') AND ((name <> 'LOG') AND (name <> 'ATTITUDE') AND (name <> 'TELEMETRY') AND (name <> 'K1') AND (name <> 'KA1') AND (name <> 'Q1') AND (name <> 'Q2') AND (name <> 'V1') AND (name <> 'V2') AND (name <> 'W1') AND (name <> 'W2') AND (name <> 'W3') AND (name <> 'W4') AND (name LIKE '%Q1%')));

Select detectors (tables) to process. The blue term demonstrates how to limit the processed tables to one particular assembly.
